American Sensidyne GilAir-5 gas sampling pump

The American Sensidyne GilAir-5 gas sampling pump can collect dust and various poisonous gases, and can meet various sampling requirements of occupational health and CDC and other testing units. Users can choose the programmable Gilair-5RP air sampling pump for scheduled and fixed-point sampling. Gilair-5 air sampling pump can be installed with a cyclone separator to collect respiratory dust and an absorption bottle to collect various poisonous gases. Gilian Gilair-5 is a personal general-purpose air sampling pump with a user-friendly design. It can be worn on workers for sampling atmospheric dust, gas or vapor, or installed on a chassis and fixed on a tripod for VOC sampling of indoor air. The sampling pump can also be equipped with sampling accessories such as filter boxes, filter membranes, cyclones, adsorption bottles and adsorption tubes.
category:

Sensidyne Air Sampler

Category:

The American Sensidyne GilAir-5 gas sampling pump can collect dust and various poisonous gases, and can meet various sampling requirements of occupational health and CDC and other testing units. Users can choose the programmable Gilair-5RP air sampling pump for scheduled and fixed-point sampling. Gilair-5 air sampling pump can be installed with a cyclone separator to collect respiratory dust and an absorption bottle to collect various poisonous gases. Gilian Gilair-5 is a personal general-purpose air sampling pump with a user-friendly design. It can be worn on workers for sampling atmospheric dust, gas or vapor, or installed on a chassis and fixed on a tripod for VOC sampling of indoor air. The sampling pump can also be equipped with sampling accessories such as filter boxes, filter membranes, cyclones, adsorption bottles and adsorption tubes.
Application fields of American Sensidyne GilAir-5 gas sampling pump:
•Scheduled poison sampling in the workplace
•Individual dust sampling at the workplace
• Fixed-point toxic gas sampling in the workplace
American Sensidyne GilAir-5 gas sampling pump product features:
•Constant current sampling, automatically compensates for flow loss within a wide pressure range, and the error value is controlled within ±5%
•When the flow rate exceeds ±5% of the original set value or the battery is insufficient, the alarm light lights up
•Safe back pressure enables error-free operation for 8 hours
•Low flow module can be installed at any time for low flow sampling
• Equipped with a float flowmeter, the approximate sampling flow rate can be known at any time
•Basic type, time display type and time programming type are available for selection
•Time programming type provides delayed start time 9999min and 6 programming positions
American Sensidyne GilAir-5 gas sampling pump product parameters:
Total flow range (with flow rate ±5% control): 1~5000 cc/min back pressure can withstand 29” H2O
Constant current and low flow (with flow rate ±5% control): 1~500 cc/min back pressure can withstand 25” H2O
Constant pressure and low flow: 1~750 cc/min back pressure can withstand 18 ± 3” H2O
Rechargeable battery: Nickel Cadmium 6.0V 1.8 Amp. hours
Weight: 0.64kg
Dimensions: 9.1 x 9.9 x 5.1 cm
Certifications: ATEX, Ex, UL, Class I, Groups A.B.C.D, Class II, E, F, G and Class III; Div I; Temp, Code T3C
