Rigol DHO1072 – 2 Channel / 70 MHz Digital Oscilloscope

$699.00

High Resolution 2 Channel, 70 MHz Digital Oscilloscope – 12 bit, 1 GSa/sec, 50 MPts Memory

SKU: Rigol DHO1072 - 2 Channel / 70 MHz Digital Oscilloscope Category:

Description
Rigol DHO1072
70 MHz bandwidth
2 analog channels
Up to 2 GSa/s real-time sample rate
50 Mpts maximum memory depth (100M with option DHO1000-RLU-01)
Standard serial decoding: SPI, I2C, RS232/UART, CAN and LIN
2 Channel / 70 MHz Digital Oscilloscope
The DHO1000 series provides improved signal integrity and value with Rigol’s latest oscilloscope technology. The UltraVision III platform, combined with a new ASIC chip design that provides true 12-bit samples makes the DHO1000 a great solution for benchtop applications where noise and accuracy are paramount. With bandwidths from 70 MHz to 200 MHz, these 2 and 4-channel oscilloscopes have Rigol’s best signal visualization capabilities. The DHO1000 series is a powerful entry-level solution for engineers seeking next-generation signal quality and value.

Model Channels Bandwidth Vertical Res. Max Sample Rate
DHO1072 2 + EXT 70 MHz 12 bit 2 GSa/s
DHO1074 4 + EXT 70 MHz 12 bit 2 GSa/s
DHO1102 2 + EXT 100 MHz 12 bit 2 GSa/s
DHO1104 4 + EXT 100 MHz 12 bit 2 GSa/s
DHO1202 2 + EXT 200 MHz 12 bit 2 GSa/s
DHO1204 4 + EXT 200 MHz 12 bit 2 GSa/s
12 bit resolution – 16x improvement in quantization uncertainty
RIGOL’s latest oscilloscope technology includes a new custom chipset design enabling sampling with true 12 bit resolution. This reduces the quantization level between bits by a factor of 16. These high resolution samples improve signal fidelity and analysis capabilities for signals from power to communications.
Low noise
Rigol’s new ASIC chipset with dramatically lower front end noise makes the most of 12 bit analog to digital converters with a significantly lower noise floor. With the noise reduced by a factor of 5 compared to UltraVision II oscilloscopes, analyze smaller signal artifacts with a combination of speed and accuracy.
Ultra Acquire Burst Capture
Capture and visualize events at up to an equivalent rate of 1.5 million waveforms per second. Set your frame number to capture and visualize using a density, waterfall, perspective, or mosaic display. Utilize UltraAcquire to capture small, dynamic changes within a complex signal.
Useful long memory – Record, navigate, and analyze with flexible memory
With up to 100 Million points in a single capture, use the deep memory to record events, navigate long continuous captures, or even further reduce the noise with high resolution mode. Work with the deep memory using precision measurements for complete signal analysis.
Standard memory is 50Mpts, it can be increased to 100Mpts with option DHO1000-RLU-01.
Applications

An oscilloscope is an important tool for making power supply measurements. With up to 12-bit vertical resolution, the DHO1000 series makes it easy for you to perform ripple measurement and quality test.
This series redefines what you can expect in an entry-level oscilloscope by providing excellent noise performance and 12-bit high resolution, providing basic functionality for higher education.
The 10.1-inch large HD touch display enables better view of signals. Large memory depth and the Autoscale function make it ready for testing of embedded system designs.
With standard CAN and LIN serial decoding functions, it provides a more affordable solution for automotive electronics testing.
User interface overview

1 Waveform View 8 Result Sidebar
2 Run State Label 9 Notification Area
3 Horizontal Timebase Label 10 Split-screen Display
4 Sample Rate & Memory Depth 11 Math Labels
Label
5 Horizontal Delay Label 12 Channel Labels
6 Trigger Label 13 Function Navigation Icon
7 Function Toolbar

Front panel overview
Please note, the image below shows a four-channel model.

1 10.1” Capacitive Touch Screen 9 Trigger Controls
2 Multipurpose Knobs 10 Vertical Controls
3 Measure Key 11 Horizontal Controls
4 Cursor Key 12 Probe Compensation Signal
Output Terminal/Ground Terminal
5 Analyse Key 13 Analog Channel Input Terminals
6 Touch Lock Key 14 USB HOST Port
7 Common Tools Keys 15 Power Switch
8 Quick Action Key (Self-defined
function)

Rear panel overview

1 Trigger Output Connector 6 USB DEVICE Port
2 External Trigger Input Connector 7 LAN Port
3 10 MHz Reference Clock Input Connector 8 AC Power Cord Connector
4 10 MHz Reference Clock Output Connector 9 Fuse
5 HDMI Connector 10 Security Lock Hole
